The advanced solar battery storage delivers safer and more efficient energy storage.
Compatible with all leading inverters, E-Box-48100R is a smart choice for battery replacement, expansion or a new installation. The solar battery storage which enable homeowners to store energy generated from renewable sources, reducing their reliance on the grid.

Battery ModelE-BOX-48100R
ChemistryLFP
Nominal Voltage51.2V
Voltage Range47.5V-58V
Nominal Capacity100Ah
Nominal Energy5.12kWh
Unit Dimension (LxWxH)17.32" x 24.41" x 4.61"
Unit Weight112.5lbs
Peak Current102A @15s
Maximum Continuous Discharge Rate100A
Standard Continuous Discharge Rate50A
Maximum Continuous Charge Current100A
Standard Continuous Charge Current50A
Round-Trip Efficiency≥95%
Cycle Life≥6000cycle
Calendar Life≥10years
Communication ProtocolRS485, CAN,RS232
Operating Temperature14°F ~ 122°F
Connect styleParallel
Storage Temperature<1month: -4~113°F
1-3months: -4~95°F
3-12months: 68~77°F
