Engineered for commercial and industrial applications, the Pytes HV48300SE MAX integrates Tier-1 LFP cells with a multi-level BMS to deliver unmatched safety and reliability. This all-weather (IP55), high-capacity cabinet is your foundation for a resilient and intelligent energy ecosystem.
Tier-1 Automotive-grade LFP 314Ah Cells
Multi-level BMS Monitoring and Active Fire Suppression
NFPA 68/69, UL 9540, UL 9540A, UL1973 Compliant
Air-cooling System
Built-in Module-level Fans
IP55 Rated Water & Dust Proof Cabinet
Modular by Design, Scalable on Demand:
Scale Seamlessly to MWh-level Capacity
Wide Voltage Operation Range
Universal Mounting Structure
Support Various Inverter Models
Remote Monitoring and Upgrading with Pytes Battery Cloud
Local Stock for Faster Delivery
Local Team Provides Comprehensive Services
| Battery Module | |
|---|---|
| Battery Chemistry | Lithium Iron Phosphate (LFP) |
| Battery Module Nominal Voltage | 51.2V |
| Battery Module Nominal Capacity | 44.8~57.6V |
| Battery Module Nominal Capacity | 314 Ah |
| Battery Module Energy | 16.076kWh |
| Weight | 262 ± 11 lb / 119 ± 5 kg |
| System | ||
|---|---|---|
| Max. Battery Pack Internal Configuration 1 | 7S2P | 15S1P |
| Rated Energy | 200.70kWh | 215.04kWh |
| Rated Power | 100.35kW | 107.52kW |
| Operating Voltage | 313.6 ~ 4032 V | 672~ 864V |
| Rated Charge/Discharge Current | 140 A*2 | 140A |
| Peak Charge/Discharge Current | 170 A*2 (@60 s) | 170 A (@60s) |
| General | ||
|---|---|---|
| Dimensions(WxDxH) | 47 x 43 x 89 in (1200 x 1100 x 2250 mm) | |
| Weight (lb / kg) | 5310.94 / 2409 | 5511.56 / 2500 |
| Ingress Protection Rating | IP 55 | |
| Cycle Life 2 | 6000cycles | |
| Warranty 3 | Battery system: 3 Years 4 Battery module: 10 Years | |
| Environmental | |
|---|---|
| Operating Temperature | Charging: 32°F ~ 131°F (O°C~SS°C) Discharging: -13°F ~ 131°F (-25°C~55°C) |
| Operating Altitude | ≤6561.68 ft(2000m) |
| Relative Humidity | 5%-95 %, non-condensing |
| Fire Suppression System | |
|---|---|
| Level 1: Detection & Ventilation | Hazardous gas detection activates ventilation system |
| Level 2: Aerosol Suppression | Heat and smoke detection activates aerosol fire suppression system |
| Level 3: Pressure Relief | The explosion relief valve opens automatically if internal pressure exceeds safe limits |
| Level 4: Fire Hose Connection Port | Equipped with a fire hose connection port for firefighter hose attachment |
| HVAC | |
|---|---|
| Max. Cooling Capacity | 5000 W (L35) |
| Max. Heating Capacity | 2500 W |
| Ingress Protection Rating | IP55 |
| Compliance | |
|---|---|
| Certifications | UL 9540 Ed.3 (2023), UL 9540A, UL 1973, UN 38.3 |
1. Flexible Configuration:
1P (1*BCU): Number of connectable BMUs ranges from 1 to 15. Voltage Range: 44.8V x (1 ~ 15) ~ 57.6V x (1 ~ 15).
2P (2*BCU in paralle): Number of connectable BMUs ranges from 1 to 7 for each BCU. Voltage Range: 44.8V x (1 ~ 7) ~ 57.6V x (1 ~ 7).
2. Operating conditions: 77°F (25°C), 0.5C @ 90% DOD, ret @70% (EOL).
3. Warranty: 3 years for the whole battery system, 10 years or 6000 cycles for the battery (whichever comes first).
4. Optional 2 year warranty extension available for purchase.
