V5° Bracket
5.12kWh
Up to 6 x V5°
Floor Mount
SGCC(Galvanized Steel)
20.48kWh
4 x V5°
Floor Mount
SGCC(Galvanized Steel
IP55, NEMA 3
Integrated Busbar & DC Circuit Breaker
| Battery Model | V5 |
|---|---|
| Electrical | |
| Chemistry | LFP |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 230Ah |
| Nominal Energy | 11.78kWh |
| Usable Energy | 10kWh |
| Recommended Charge/Discharge Current | 115A(5.88kW) |
| Peak Charge/Discharge | |
| Peak Discharge Current | 300A@15s |
| General | |
| Chemistry | LFP |
| Communication Interface Dimensions(L x W x H) | RS485 / CAN / WIFI / Dry Contact / 25.20 x 9.06 x 20.47inch /40 x 230 x 520mm |
| Weight | 220.5lbs / 100kg |
| Operating Temperature | Charge: 32~131°F / 0~55°C / Discharge -4~131°F / -20~55°C |
| Cycle Life* | 8000 Cycles |
| Altitude | <13123.35ft / 4000m |
| Warranty | 12 Years |
| Ingress Protection | lP55 |
| Mounting Method | Wall / Ground (W/ Optional Battery Tray) |
| Heating Pad (Integrated) | Temperature Rise: 14.4°F/h / 8°C/h |
| Add-on Functionalities | |
|---|---|
| WIFI Connection | Remote monitoring and upgrade |
| Heating Pad | Temperature Rise: 18F/h Operation Temperature: -0.4°F~50°F |
| Scalability | 16 pcs (81.92kWh)in a group 6 groups (491.52kWh) in a system w/a Hub |
